Goman 2.5T Tracked Multi-loader Crawler Carrier CC25 is a powerful and versatile tracked carrier designed for heavy-duty material transport in demanding environments. With a maximum load capacity of 2.5 tons, it is ideal for applications in construction, mining, agriculture, landscaping, and industrial logistics.
The CC25 features an integrated control system on its platform, including both an on-board control console and a remote controller, providing users with flexible operation options for precision handling in complex or hazardous zones.
Its flatbed measures 2.38mX1.25m, offering ample loading space. The crawler span width is hydraulically adjustable, allowing the tracks to extend to a maximum width of 1.7m. This adjustment increases platform height to 0.84m and improves ground clearance and stability when needed.
A unique feature of the CC25 is its hydraulically adjustable crawler tilt function, which enables one crawler to extend and form a fixed angle when the machine travels transversely on slopes (up to 25% or 14°). This ensures the loading platform remains level, even on uneven terrain.
The crawler carrier is equipped with a tow hook, enabling it to tow loads up to 5,454 kg, expanding its utility in transport and logistics.
Powered by a robust 18 HP gas engine, the Goman CC25 delivers reliable performance. It has a climbing capacity of up to 32%, with a maximum working slope rating also at 32%, making it suitable for most rugged and off-road conditions.
With a stowed dimension of 2.47mX1.7mX0.84m and an operating weight of 1,940 kg, the CC25 balances strength with mobility.
Additional features include a simple control console, automatic leveling, and emergency lowering system, ensuring safe, efficient, and user-friendly operation in various working environments.
Please contact an expert for more details!
