30m Spider Lift | Infrastructure Maintenance & Building Access | 200kg Payload | CE/ANSI Compliant

Standard Features & Advantages:

►Compact design, AC 16A outlet in the basket

►German made HMI and PLC controller, stainless control box

►cable control, integrated radio function for free

►Self-leveling basket, and interchangeable with hydraulic

winch or other hydraulic tools as option

►Automatic outrigger leveling and basket rotation

►Hydraulic adjustable crawlers for height and width

►Hydraulically arms and outrigger interlock

►Weight dispersal low ground pressure

►Made of high tensile steel, hot dip galvanized boom available

►Reach standard of ISO, CE and ANSI

30m Reach: Suitable for high-rise tasks (window washing, tree trimming, signage installation).

Horizontal Outreach 12.6m at 200kg: Access over obstacles (e.g., walls, machinery).

Compact Design: Narrow chassis and articulating booms allow navigation through tight spaces (e.g., alleys, indoor facilities).

Self-Propelled Movement: Autonomous mobility reduces manual repositioning, saving time and labor.

Hydraulic Outriggers/Stabilizers: Automatic leveling ensures stability on slopes, reducing setup time compared to traditional lifts.

Stabilization Systems: Outriggers and tilt sensors prevent tipping.

Electric/Hybrid Options: Zero emissions and quiet operation for indoor use (e.g., warehouses, museums).

Stability on Uneven Ground: Tracked systems distribute weight evenly, enabling operation on soft, muddy, or uneven surfaces (e.g., construction sites, forests).

Low Ground Pressure: Tracks minimize surface damage, ideal for sensitive areas like lawns or indoor floors.

Ideal Use Cases:

u Indoor maintenance (e.g., lighting, HVAC in airports, rail-station).

u Outdoor construction (e.g., facades, bridges).

u Urban environments with space constraints.
