16m Crawler Boom Lift | Bi-leveling Tracked Lift | CE/ANSI Certified

Goman Crawler Boom Lift: Outrigger-Free & Hybrid-Powered Innovation

Goman Crawler Boom Lift revolutionizes aerial access with its outrigger-free design and hybrid power system (gas engine + lithium batteries), delivering unmatched versatility for indoor and outdoor operations. Its automatic bi-leveling chassis ensures stability and safety on slopes or uneven terrain, adapting seamlessly to challenging environments without manual adjustments. Compact, agile, and eco-conscious, this platform excels in construction, utility maintenance, and urban projects, combining rapid deployment with reduced emissions. Engineered for precision and durability, it empowers crews to tackle height challenges efficiently while minimizing downtime and environmental impact.

Availability:

Quantity:



Inquire Add to Basket

Model:
CB16
Brand:
GomanLift

Boom Lift Bi-leveling Tracked Lift Automatic Leveling Boom Light CE/ANSI Certified 16m Tracked Lift

Product Description

Standard Features & Advantages:

►Hybrid power (gas engine + battery)

►Compact design for indoor and outdoor use

►Gravity lowering (emergency lowering)

►Wireless remote control for all movement

►Load sensor and self-leveling basket

►Double axle adjustment allowing work in slope

►Adjustable black rubber crawlers for narrow access

►Plug control panel in basket

►360°non-continuous turntable rotation

►Made of high tensile steel

►Reach standards of ISO, CE and ANSI

Product Details

16m Working Height Reach: Ideal for a wide range of elevated tasks in both indoor and outdoor environments, ideal for multi-location tasks (e.g., facility maintenance working on the slopes).

6.8m Horizontal Outreach At 220Kg Basket Load: Provides reliable reach over obstacles like walls, fences, while maintaining full load capacity.

Compact Fold-up 6.17x1.75x2.09m: Features a narrow chassis and adjustable crawler structure for a compact fold-up size — enabling easy access through confined areas such as alleys, doorways, and indoor facilities.

Basket Size (LxWxH): 1.2mX0.7mX1.1m

Max Travel Speed 0-2.5 km/h:

Max Working Slope 17°

Max Gradeability 15°

Self-Propelled Movement: Allows for autonomous driving and positioning, minimizing manual handling and significantly improving efficiency on the job site.

Automatic Leveling: Ensures stable setup on a slop and reduces preparation time compared to conventional lifts.

Advanced Stabilization Systems: Integrated tilt sensors and interlocked outriggers provide enhanced safety, preventing operation under unsafe conditions.

Total Weight (approx): 5800kg
